Pattern Designer

Has been structure to respond today’s challenges in the industry :

  • Lack of communication between  departments
  • Traceability
  • Reduce human error
  • Manual interventions

But also, to respond to foreseeing when :

  • Automate the product configuration for customized garments
  • Reduced time for knowledgesharing

Photo Digitizer

Digitized ⇒ Convert cardboard or paper patterns to digital format

Auto Recognition

  • The Pattern can be converted very quickly to an electronic format
  • Gemini Photo Digitizer can automatically detect the piece contours
  • It can also automatically detect notches, internal points and internal axes

Control And Edit ⇒ You can edit the Piece properties and the properties of selected element (point, segment, internal line, internal point)

Save Time

  • Automatically capture pictures with your physical pattern
  • Images get processed fast and accurate
  • Pattern extracted in just few seconds

Quick And Easy ⇒ Inspect the result of the automatic digitizer

No Limitation ⇒ Save the pattern directly in the native format of your CAD system

Nest Expert

Optimize With NestExpert ⇒ Optimizes the nesting of cut  parts into the material surface, obeying various restrictions and nesting rules

Generate Production ⇒ Generates the optimized machine file output for single-ply, multi-ply, laser, knife, ultrasonics or waterjet cutters, plotters and textile printer

Integrate With Other Solutions ⇒ Can be used together with Gemini PatternDESIGNER, integrated with Gemini CutPLANNER, or with any other CAD application which can export shapes for nesting

Cut Planner

» Automatic and Manual lay definition

» Automatic order optimization

» Cutting room order report

» Export for plotters, cutters

» Export for other CAD systems

» Integration ERP systems using OTX open format
